Numeric 1phase 10 KVA UPS on rent

About Numeric 1phase 10 KVA UPS on rent

Numeric Model HPE 10 kVA UPS (Enhanced Efficiency Version)

Power Rating:

• Nominal Rating: 10 kVA / 9 kW

• Power Factor: 0.9 (Improved from 0.8 for better real power delivery)

Rectifier:

• Type: IGBT-based

• Input Transformer Built-in: Yes

• Input THDi: <3% (Improved for cleaner input current)

Physical Characteristics:

• Dimensions (D W H): 600 mm 450 mm 1100 mm (Compact Design)

• Weight: 70 kg (Optimized internal components)

Input:

• Configuration: 3-phase, 4-wire + PE

• Voltage: 400 VAC

• Voltage Range: 280480 VAC (Wider range for unstable grid conditions)

• Frequency: 50/60 Hz 10%

• Power Factor: >0.99 (Excellent input performance)

Battery:

• Battery Type: SMF / VRLA or Li-ion (optional)

• No. of Cells: 12 V per cell / 28 cells

• DC Bus Voltage: 336 VDC

• Battery Charging Current: 6 Amps (Faster charging)

• Battery Management: Advanced battery health diagnostics (new feature)

Output:

• Voltage: 230 VAC (configurable to 220/240 VAC), 1 Phase

• Voltage Regulation: 1%

• Frequency Regulation: 50/60 Hz 0.5 Hz (Better control)

• Crest Factor: 3:1

• Max Units in Parallel: Up to 4 Units

• Slew Rate: 1 Hz/sec

• Output THD: <1% (Linear Load), <3% (Non-Linear Load) improved for sensitive loads

Efficiency:

• AC to AC Efficiency: 92% (Improved from 84%)

• ECO Mode Efficiency: Up to 97%

• Overload Handling:

  • 110% for 15 minutes

  • 125% for 5 minutes

  • 150% for 30 seconds

System Features:

• Galvanic Isolation: Yes

• Internal Static Bypass: Yes

• Hot-Swappable Components: Yes (Optional)

• Inverter Transformer: Built-in

Environment:

• Noise Level: <55 dBA (Quieter operation)

• Operating Temp: 0 to 50C

• Storage Temp: -15 to 70C

• Humidity: 095% RH non-condensing

• Altitude: Up to 1500 m without derating

Communication & Monitoring:

• SNMP/Web Interface: Yes

• RS-485 / Modbus: Yes

• Dry Contacts: Configurable

• LCD Touchscreen Display: Yes (new)

• MultiLink / Monitoring Software: Included

• Mobile App Monitoring: Optional
