Emerson Single phase 10 KVA UPS on rent

About Emerson Single phase 10 KVA UPS on rent

Liebert Super 400D 10 kVA UPS Summary

Power Rating:

• Nominal Rating: 10 kVA / 8 kW

Rectifier:

• Type: IGBT

• Input Transformer Built-in: Yes

Physical Characteristics:

• Dimensions (D W H): 650 mm 450 mm 1170 mm

• Weight: 75 kg

Input:

• Configuration: 3-phase, 4-wire + PE

• Voltage: 400 VAC

• Voltage Range: 300480 VAC

• Frequency: 50 Hz

• Frequency Range: 4565 Hz

• Power Factor: Unity at Rated Load

• Input THD: <5%

Battery:

• No. of Cells: 12 V per cell / 28 cells

• Type: SMF / VRLA

• DC Bus Voltage: 336 VDC

• Battery Charging Current: 4 Amps

Output:

• Voltage: 220/230/240 VAC, 1 Phase

• Power Factor: 0.8

• Voltage Regulation: 1%

• Frequency Regulation: 50 Hz 1 Hz

• Max No. of Units in Parallel: Up to 3 units

• Crest Factor: 3:1

• Slew Rate: 1 Hz/sec

• Voltage Distortion (THD): <2% on Linear Load, <5% on Non-Linear Load

Efficiency:

• AC to AC Efficiency: 84%

• Overall Capacity (on Line + Battery Mode): 110% for 10 mins, 125% for 1 min, 150% for 10 secs

System Configuration:

• Transformer: Inverter Transformer Built-in

• Galvanic Isolation: Yes

Environment:

• Noise Level: <60 dBA

• Operating Temperature: 0 to 40C

• Storage Temperature: -10 to 70C

• Humidity: 095% Relative Humidity

Communication:

• SNMP / Modbus / Web: Optional

• Dry Contact: Optional

• Multilink Software: Optional

• SMS Facility: Optional

• Serial Configuration / RS-485: Yes
